Automatic Cot Grinding Machine - Table Traverse Principle

Fascination:
The machine has a full width grinding wheel of 200 mm on table traverse system with hydraulic movement,  it has the PLC base timer & positive driven centreless grinding attachment which is designed to grind Ring Frame & Speed Frame top rollers for auto-grinding. The centreless attachment is operating by pneumatic system. A separate 25 mm width grinding wheel is provided to grind draw frame & comber top roller between two centres.

Application:
Machine is suitable for grinding all types of top rollers like Ring frame, Speed frame, Draw frame, Comber, OE, texturizing, Elite rollers etc.
