AQUASPLICER® 4923B

AQUASPLICER®4923B - 4925B

The knotless joining of particular yarns solely by compressed air does not always produce sufficiently strong joints for adequate performance in the downstream processes. An efficient and original ends preparation system followed by a splicing blast where water and air are combined
in pre-determined proportions produces very strong and imperceptible joints on hygroscopic yarns such as linen or cotton. Utilizing a common water supply, the joining area of the device is completely sealed from other parts of the unit, ensuring cleanliness and reducing maintenance
to an absolute minimum. After the introduction of the yarn ends, the pressure of a trigger by the operator activates the Actuator (Code 390B), which automatically performs the entire cycle, producing the optimum results without any particular operator skills.
Combined with the A.T.S. system, AQUASPLICER® 4923B can be attached to traditional winding and twisting machines with specific fittings catering for vertical movement when applied to warping creels for top to tail transfer. Joining capacity of the AQUASPLICER® 4923B covers a count range from Ne 3 to Ne 200.

The new AQUASPLICER® code 4925B has been designed on purpose to splice elastomeric core/staple cotton yarns, as well as the complete range of yarns usually spliced by code 4923B.

SKU : SKU02750

Category : Splicers

Datasheet : -

Inquiry

Tags :
